GR Powder Granulators

The GR Series consists of the GR60, GR90 and GR160, with the number denoting the diameter of the machine’s roller in mm. They each work on the same principle, involving an oscillating metal cylinder that acts against an easily changed metal mesh. With powerful motors, adjustable speed, and carefully engineered oscillation for maximum efficiency and minimum energy requirement, these machines produce granular materials of the highest quality and consistency. Popular choices for companies in the pharmaceutical, chemical, food and ceramics industries, all the granulators in the series are built from stainless steel, and constructed to meet GMP standards. They are simple to operate and maintain, easy to clean, and designed to satisfy the stringent hygiene requirements needed for food production. They are also rugged and durable, with minimal maintenance needs, and will provide reliable operation for many years into the future.

Main benefits of the GR Powder Granulators

• Engineered from stainless steel for durability and hygiene
• Built to meet GMP standards
• Carefully engineered oscillating motion for consistent, homogeneous granules
• Adjustable speed
• Rugged motors that require little maintenance
• Easily changed metal mesh
• Suitable for food use, chemical production, tabletting, ceramics and many other applications
• Suitable for dry granulation
• High capacity
• Low energy consumption
• Easy to use, no special training required.

Features

The GR Granulators feature a highly effective oscillating mechanism that enables damp or dry materials to be granulated quickly and to a very high standard of consistency and homogeneity. This makes them ideal for use in demanding applications. Thanks to their stainless steel construction they also comply with the strict hygiene requirements for food processing. These machines are GMP compliant, and have been carefully designed from the outset to meet the need for an energy efficient, reliable solution with high working capacities and low maintenance.

The motors in this series range from 250 watts up to 2.2 kW, meaning that the GR series is a comprehensive solution that covers the granulating requirements of virtually any user. With adjustable speeds and easily changed meshes, the GR granulators can cope with a wide variety of raw materials.

GR Granulators in Use

The GR granulators are exceptionally easy to use and maintain. Simply add the powder or other raw materials to the hopper, switch on, and let the machine process the materials. Finished granules are deposited on a lift-out tray beneath the machine.

As well as medical and tabletting applications, these granulators are ideal for granulating the coagulated material formed during storage or chemical processing, processing porcelain or plastic mixtures into granules, processing candy and sugar mixtures, or for barley milk products.

As all relevant parts are stainless steel, the granulators are easy to clean, while maintenance is kept to a minimum by the thoughtful design and rugged construction.

LFA's View

The GR series is a highly effective granulating solution that gets the job done with minimal fuss. The motors vary greatly in their capacity, which means that between them, one or other of the machines is bound to suit almost any user’s requirement, large or small. The oscillating action is an efficient, proven and reliable technology for producing consistent granules, and an ability to process both damp or dry raw materials makes these granulators as versatile as they are dependable. Cost effective to buy and economical to run, these machines produce excellent results with little training and in the shortest time.

Technical Specifications

Model	GR60	GR90	GR160
Diam. of rotor (mm)	60	90	160
Capacity (kg/h)	20-30	50-100	200-300
Rotation angle	360°	360°	360°
Rotation speed	46	50	55
USA Power	0.25kW, 1 Phase, 110v, 60Hz	0.55kW, 3 Phase, 220v, 60Hz	2.2kW, 3 Phase, 220v, 60Hz
UK Power	0.25kW, 1 Phase, 240v, 50Hz	0.55kW, 3 Phase, 440v, 50Hz	2.2kW, 3 Phase, 440v, 50Hz
Weight (kg)	75.5	150	280
Overall size (mm)	460 x 550 x 570	750 x 460 x 840	970 x 560 x 1240

**If not specified, the default mesh size the Granulator will come installed with is 14 mesh/1410 Micron**
