Top Cam Drive Shaft - TDP 5


We only supply spare parts to machines purchased directly from us. Please enter your serial number to make a purchase.

  • Genuine TDP 5 Part
  • Fast Delivery
  • Installation Videos Available
Prefer to pay by Invoice? Request Quote

TDP 5 Version

Finding out if your machine is a version 1 or version 2 TDP 5 is quite simple. On the top back of your machine, you will see a metal plate, this is where the machine serial number is. If the serial number starts with AEAA, you have a version 1 TDP 5. If the serial number starts with AEBA, you have a version 2.


The Top Cam Drive Shaft on the TDP 5 runs from the Left Hand Cog to the Fly Wheel and keeps the entire TDP5 press in time. The timing cam for the Lower Drift Pin Assembly and the timing Cam for the Boot also both sit on the cam. Finally in the middle is the Eccentric Sheave that controls the timing of the upper drift pin assembly.

This part is notoriously difficult to change and should only be attempted by experienced mechanics, engineers or individuals that have alot of experience with the TDP 5 from LFA Tablet Presses. If you are worried about attempting this your self please do get in contact.

The cam comes with out any of the attachments on it. You will also require a large strong rubber mallet to be able to insert the Top Cam Shaft in to the TDP 5 base. Maintenance and servicing on your TDP just got a great deal easier with help from LFA Tablet Presses. If you have any concerns with fitting this part your self we are able to do it for you. You will however need to get the press to us.

As soon as you receive your parts you will discover why all of LFA's parts are guaranteed. LFA has the highest customer retention rate in the industry. Try our parts and repairs service to find out why.

Imagine not having as much downtime on your production line.

You will instantly be able to see the superior quality. Never fear lengthy reductions in output again. LFA offers express delivery across the world giving you the peace of mind to focus on improving your business.

Let LFA help your business perform more smoothly. LFA's authentic TDP parts are proven effective and safe by our own extensive quality control screening procedure.

All of our parts are brand new and delivered rapidly to you. Purchase these premium TDP parts today and you will not be disappointed.
